Pella® Reserve™ – Contemporary Wood Bifold Patio Door

Create a seamless transition from indoors to outdoors with a sleek Pella Reserve – Contemporary extruded aluminum-clad wood bifold patio door. Featuring narrow sightlines and pure corners, these thermally broken patio doors deliver on authentic contemporary design principles. Small bifold doors can also be used as a pass-through window for an outdoor bar.

  • Out-swing bifold doors are NFRC-rated, providing energy efficient options, even for harsh climates, and feature air, water and structural ratings.
  • Configurable to your exact space with panels that stack to one side or open in the middle, up to 10 expansive panels wide.
  • Several sill design options to create a seamless transition between the indoors and outdoors.

Talk to a Pella Rep for Pricing

Reserve - Contemporary Bifold Patio Door Features

    • Minimalist Design

      • Expansive Custom Sizing and Configurations

        • Best Limited Lifetime Warranty For Wood Patio Doors19

        Design Options

        Pella Reserve products offers exquisite wood types to enhance your home's design. And, we stand behind them with a Limited Lifetime warranty.

        Materials

          • pine wood

            Pine

            • unfinished mahogany corner section of a window

              Unfinished Mahogany

              • douglas fir wood window material

                Douglas Fir

              Materials

              Pella's EnduraGuard® wood protection formula has three active ingredients. This powerful combination, together with our immersion-treatment method, helps ensure strong protection on every exterior wood surface of our products. The result is advanced protection against the effects of moisture, decay and stains from mold and mildew.

              Downloads & Specifications

              Design & Performance
              Specifications
              2D Cross Section
              3D & BIM
              Sell Sheets
              • illustration of a bifold patio door reserve traditional
              • reserve contemporary bifold patio door cross section

              Reserve - Contemporary Bifold Patio Door Specs & Install Details

              • Sleek, squared-off sash profiles combined with through-stile construction and expansive glass exude the tenets of contemporary design
              • Performance rating of R15-LC2531
              • Available in stacking or bi-parting combinations with two to 10 panels in sizes up to 425” x 119-1/2” in 1/8” increments
              • Cutting-edge integrated security sensors preserve the beauty of Pella Reserve patio doors, streamline security installation and ensure no warranty loss is caused by post-installation drilling
              • Can be used as a small passthrough window or a large door with a passage panel
              Frame
              • Wall depth is 4-9/16" with frame depth of 6" (152 mm).
              • Factory finished jamb extensions available ordered separately from unit and field applied.
              • Sill is 2-5/16" standard profile, 1-1/4" low profile or flush profile.
              • Material and finish is thermally broken extruded aluminum with Bronze anodized finish.
              • Frame width greater than 240" (6096mm) will receive two pieces for head and two pieces for sill that require splicing during installation.
              Door panels
              • Exterior surfaces are clad with extruded aluminum.
              • Panel stiles and rails are three-ply construction, randomly finger-jointed blocks laminated with water-resistant glue and veneered on both sides.
              • Units over 8' height have panel stiles constructed with LVL core with fingerjointed edge bands on both sides and veneered on both faces.
              • Corners are urethane-silicone hybrid sealed and secured with metal fasteners.
              • Panel thickness is 2-1/16" (52mm).
              Weatherstripping
              • Foam leaf seal along jambs, head, and sill of frame.
              • Foam leaf seal along astragal
              • Mohair along the head of frame.
              • Foam leaf seal along the stiles of panel.
              • Bristle rainscreen along bottom of panel.
              • Neoprene foam strips between off-set panel hinges.
              Hinges
              • Doors will have a Top Pivot Hinge, Middle Pivot Hinge and Bottom Pivot Hinge connecting a panel to the jamb where appropriate.
              • Doors up to 8' 7/8" frame height will have a top hinge, bottom hinge, and one middle hinge connecting adjacent panels.
              • Doors over 8' 7/8" frame height will have a top hinge, bottom hinge, and two middle hinges connecting adjacent panels.
              Passage Door Locks (when applicable)
              • Mortised and keyed multi-point locking system, center deadbolt and shoot-bolts at head and sill will engage simultaneously.
              • Doors 8' 0" frame height and below will have one strike at the head, one strike at the sill and one center deadbolt.
              • Doors over 8' 0" frame height up to and including 10' 0" frame height will have one strike at the head, one strike at the sill and three locking points at the stile.
              • Active handle set with solid brass handle and keylock with K-keyway cylinder.
              Passive Panel Locks
              • Hardware style is Dualpoint Lock Handle (on applicable panels not adjacent to passage panel).
              • Handle Height at Typical @ 36", Window reach @ 10.5", Greater than 54" from bottom of panel.
              • Mortised multi-point locking systems with shoot-bolts at head and sill will engage simultaneously.
              exterior of a reserve contemporary home at dusk

              Pella® Reserve™

              Authentically historic or pure contemporary, trust us to make your vision a reality with Pella Reserve patio doors. Our traditional and contemporary designs are meticulously crafted to exude your selected style, from historic putty profiles and the traditional look of individual windowpanes to sleek corners and expansive glass.
